Wafer

Description

Ductile Iron Wafer Butterfly Valve with gearbox. EPDM Liner. Stainless Steel Disc.

Connection

Wafer to suit PN10, PN16 & ANSI 150 Flanges

Approvals/ other

CE and WRAS Approved

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Wafer Butterfly Valve with gearbox. EPDM Liner. Stainless Steel Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer to suit PN10, PN16 & ANSI 150 Flanges

Approvals/ other

CE Approved.

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

PN25 Ductile Iron Butterfly Valve Wafer Type. EPDM Liner. Stainless Steel Disc. ISO Top.

Stock Availability

Subject to factory lead time.

Connection

Flange mounting PN25 only

Pressure

25 Bar Rated

Temperature

-10°C to +110°C

Description

PN25 Ductile Iron Butterfly Valve Wafer Type. EPDM Liner. Stainless Steel Disc.

Stock Availability

Subject to factory lead time.

Connection

Flange mounting PN25 only

Pressure

25 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type. Available from 2" to 12". EPDM Liner. Stainless Steel Disc. ISO Top. To suit PN10, PN16 and ANSI 150 Flanges. Gearbox available. Note: We strongly advise gearbox on all 8", 10" and 12" valves.

Connection

Wafer

Pressure

Up to 16 Bar

Temperature

-10°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. Available 1.1/2" to 24" (see separate datasheet for 16" to 24"). BS5155 (BS EN593). Epoxy Coat Finish. ISO 5211 Direct Mount.

Connection

Universal Flange Mounting PN16 PN10 ASA150

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. BS5155 (BS EN593). Epoxy Coat Finish. ISO 5211 Direct Mount.

Connection

Universal Flange Mounting PN16 PN10 ASA150

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type. Available from 2" to 6". EPDM Liner. Stainless Steel Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Stainless Steel Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to 110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Stainless Steel Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to 110°C

Description

Ductile Iron Wafer Butterfly Valve. NBR Liner. Stainless Steel Disc. ISO Top.

Connection

Wafer to suit PN10, PN16 & ANSI 150 Flanges

Approvals/ other

CE Approved

Pressure

16 Bar Rated

Temperature

-10°C to +90°C

Description

Fixed Orifice Regulating Wafer Butterfly Valve. Position Indicator. Fixed orifice with ±5% flow measurement accuracy. Supplied with 2 extended test points. Gearbox has multiple lockable positions. The ART 2115GB consists of an ART 115 Butterfly Valve coupled to a Fixed Orifice Flanged Metering Station to form a fixed orifice commissioning set with regulation and isolation capabilities. Supplied fully assembled.

Stock Availability

Subject to factory lead time.

Connection

Flange Mounting PN16 only.

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Wafer Butterfly Valve. EPDM Liner. Ductile Iron / Nickel Plated Disc. ISO Top

Connection

Wafer PN10 PN16 & ASA 150 Flanges

Approvals/ other

CE Approved

Pressure

16 Bar Rated

Temperature

-20°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type. Available from 2" to 12". EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

16 Bar Rated

Temperature

-10°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

16 Bar Rated

Temperature

-10°C to 110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

16 Bar Rated

Temperature

-10°c to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type. Available from 2" to 6". EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to +110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to 110°C

Description

Ductile Iron Butterfly Valve Wafer Type with gearbox. EPDM Liner. Nickel Plated Ductile Iron Disc.

Stock Availability

Subject to factory lead time.

Connection

Wafer

Pressure

25 Bar Rated

Temperature

0°C to 110°C

Description

PN40 Stainless Steel Dual Plate Wafer Check Valve. Viton seat. PN40 rated.

Connection

Wafer Pattern to PN10, 16, 25 & 40 & ANSI 150 & 300 Flanges

Pressure

40 Bar Rated

Temperature

-25°C to +180°C

Description

Stainless Steel Disc Wafer Check Valve. 'O' Ring Viton.

Connection

Wafer Pattern to suit PN16 & ANSI 150 Flanges

Approvals/ other

ATEX Approved "O" Ring Viton.

Pressure

16 Bar Rated

Temperature

-25°C to +180°C

Description

Stainless Steel Spring Wafer Check Valve

Connection

Wafer pattern to suit PN10, 16, 40 & ANSI 150 & 300 Flanges

Approvals/ other

ATEX Approved Metal Seat

Pressure

40 Bar Rated

Temperature

-25°C to +200°C

Description

PN16 Stainless Steel Orifice Plate (OP). Fixed Orifice. C/W Ext & Test Points.

Stock Availability

Sizes DN300+ are subject to factory lead time.

Connection

Wafer pattern. Fits between BS EN1092 flanged PN16.

Pressure

16 Bar Rated

Temperature

-10°C to +120°C

Description

PN25 Stainless Steel Orifice Plate (OP). Fixed Orifice. C/W Ext & Test Points.

Connection

Wafer pattern. Fits between BS EN1092 flanges PN25

Pressure

25 Bar Rated

Temperature

-10°C to +120°C

Description

ANSI Stainless Steel Orifice Plate (OP)

Stock Availability

Subject to factory lead time.

Connection

Wafer pattern. Fits between ANSI 150 flanges.

Pressure

16 Bar Rated

Temperature

-10°C to +120°C

Description

Ductile Iron Automatic Flow Balancing Valve

Stock Availability

Subject to factory lead time.

Connection

Wafer Pattern

Approvals/ other

5 Year Guarantee

Pressure

16 Bar Rated

Temperature

-20°C to +120°C
