31-40 Bar Rated

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

CE, WRAS, EN331 Gas

Pressure

Liquids
40 Bar Rated (¼" to 2")
25 Bar Rated (2½" to 4")
Gas
5 Bar Rated (¼" to 4")

Temperature

Liquids
-20°C to +140°C
Gas
-20°C to +60°C

Description

PN40 Brass Ball Valve complete with Locking Lever. Full bore.

Connection

Screwed BSP Parallel (ISO 228/1)

Approvals/ other

WRAS, EN331 Gas

Pressure

Liquids
40 Bar Rated
Gas
5 Bar Rated

Temperature

Liquids
-20°C to +140°C
Gas
-20°C to +60°C

Description

PN40 Brass Ball Valve complete with Thermal Extension. Full bore.

Connection

Screwed BSP Parallel (ISO 228/1)

Approvals/ other

WRAS, EN331 Gas

Pressure

Liquids
40 Bar Rated Gas
5 Bar Rated

Temperature

Liquids -20°C to +140°C Gas -20°C to +60°C

Description

2 Piece Brass Ball Valve. Full Bore. Tee Handles available in red, yellow, and blue.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

CE, WRAS, EN331 Gas

Pressure

Liquids 40 Bar Rated (¼" to 1") Gas 5 Bar Rated (¼" to 1")

Temperature

Liquids -20°C to +140°C Gas -20°C to +60°C

Description

2 Piece DZR Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to +130°C

Description

2 Piece DZR Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Pressure

40 Bar Rated

Temperature

-20°C to +130°C

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1)

Approvals/ other

CE, WRAS, EN331 Gas

Pressure

Liquids
40 Bar Rated (¼" to 2")
25 Bar Rated (2½" to 4")
Gas
5 Bar Rated (¼" to 4")

Temperature

Liquids
-20°C to +140°C
Gas
-20°C to +60°C

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

NPT F/F Ends (ANSI B1.20.1)

Approvals/ other

CE Approved
WRAS Approved

Pressure

40 Bar Rated (¼" - 2")
25 Bar Rated (2½" - 4")

Temperature

-20°C to +140°C

Description

PN40 Brass Ball Valve M/F Ends. PTFE seats and seals. Anti-blow out stem. Full bore. Locking lever, thermal extension and tee handle options available.

Connection

BSP Parallel M/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to 140°C

Description

PN40 Brass Ball Valve M/F Ends. PTFE seats and seals. Anti-blow out stem. Full bore. Tee Handles available in red and blue.

Connection

BSP Parallel M/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to 140°C

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

32 Bar Rated (¼" to 1") 25 Bar Rated (1¼" to 2") 16 Bar Rated (2½" to 4")

Temperature

-5°C to +110°C

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved & EN331 Gas Approved

Pressure

See datasheet for full details

Temperature

See datasheet for full details

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Taper F/F End (ISO 7/1)

Approvals/ other

WRAS Approved & EN331 Gas Approved

Pressure

See datasheet for full details

Temperature

See datasheet for full details

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

NPT F/F Ends (ANSI B1.20.1)

Pressure

40 Bar Rated

Temperature

-20°C to +150°C

Description

2 Piece Brass Ball Valve. Full Bore.

Connection

BSP Parallel M/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to +150°C

Description

2 Piece Brass Ball Valve. Full Bore.

Stock Availability

Subject to factory lead time.

Connection

BSP Parallel M/M Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-20°C to +150°C

Description

Brass Ball Valve. Full Bore. ISO 5211 Direct Mount.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated (¼" - 1") 32 Bar Rated (1¼") 30 Bar Rated (1½" - 2½") 25 Bar Rated (3")

Temperature

-20°C to +120°C

Description

3 Way 'L' Port Brass Ball Valve. Reduced Bore.

Connection

BSP Parallel Female Ends (ISO 228/1)

Pressure

32 Bar Rated (¼" - 1") 25 Bar Rated (1¼" - 2")

Temperature

-20°C to +150°C

Description

3 Way 'T' Port Brass Ball Valve. Reduced Bore.

Connection

BSP Parallel Female Ends (ISO 228/1)

Pressure

32 Bar Rated (¼" - 1") 25 Bar Rated (1¼" - 2").

Temperature

-20°C to +150°C

Description

2 Piece Flanged PN16/40 Stainless Steel Ball Valve. Full Bore. Locking Lever. ISO Direct Mount. PTFE Seats. Viton Seals.

Connection

Flanged PN16/40

Approvals/ other

ATEX Approved

Pressure

40 Bar Rated (½" - 2") 16 Bar Rated (2½" - 8")

Temperature

-25°C to +200°C (½" to 4") -25°C to +180°C (5" to 8")

Description

2 Piece Flanged PN16 Stainless Steel Fire Safe Ball Valve. Anti Static Device. Full Bore. PTFE Seats. ISO Direct Mount.  Locking Device. TUV Certified to API STD 607. ATEX Approved.

Connection

Flanged PN16

Approvals/ other

ATEX Approved.
TUV Certified to API STD 607.

Pressure

40 Bar Rated (½-2")   16 Bar Rated (2½- 4")

Temperature

-25°C to +200°C

Description

2 Piece Bronze Ball Valve. Full Bore.

Connection

BSP Taper F/F Ends (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

CE

Pressure

40 Bar Rated

Temperature

-10°C to +140°C

Description

PN40 Bronze Ball Valve. Bronze Body. Full Bore. Blow Out Proof Stem. MSS-SP-110.

Stock Availability

Not stocked in the UK.

Connection

Screwed BSP Taper (ISO 7/1) or NPT (ANSI B1.20.1)

Approvals/ other

WRAS Approved

Pressure

40 Bar Rated

Temperature

-10°C to +140°C

Description

Bronze Globe Valve. Renewable PTFE Seat.

Connection

BSP Taper F/F Ends (ISO 7/1)

Approvals/ other

BS 5154 Approved

CE Approved

Pressure

32 Bar Rated

Temperature

-10°C to +200°C

Description

PN40 Stainless Steel Dual Plate Wafer Check Valve. Viton seat. PN40 rated.

Connection

Wafer Pattern to PN10, 16, 25 & 40 & ANSI 150 & 300 Flanges

Pressure

40 Bar Rated

Temperature

-25°C to +180°C

Description

Stainless Steel Spring Wafer Check Valve

Connection

Wafer pattern to suit PN10, 16, 40 & ANSI 150 & 300 Flanges

Approvals/ other

ATEX Approved Metal Seat

Pressure

40 Bar Rated

Temperature

-25°C to +200°C

Description

PN32 Bronze 'Y' Strainer. Suitable for water, steam and oil. Screen: Woven wire 20 mesh (0.85mm aperture - 51% open area). Suitable test points available to purchase on request.

Connection

Screwed BSP Taper (ISO 7/1)
NPT (ANSI B1.20.1) version available on request.

Pressure

32 Bar Rated

Temperature

-10°C to +200°C

Description

Stainless Steel Pressure Reducing Valve. EPDM Seal.

Stock Availability

Subject to factory lead time.

Connection

BSP Taper M/M Ends (ISO 7/1)

Approvals/ other

WRAS Approved

Pressure

Inlet Pressure: Up to 40 Bar Rated
Outlet Pressure: 1 to 8 Bar
Low pressure (0.5-2 Bar) & High pressure (5-15 Bar) versions available on request.

Temperature

-10°C to +95°C

Description

Stainless Steel Pressure Reducing Valve. EPDM Seal.

Stock Availability

Subject to factory lead time.

Connection

BSP Parallel F/F Ends (ISO 228/1)

Approvals/ other

WRAS Approved

Pressure

Inlet Pressure: Up to 40 Bar Rated
Outlet Pressure: 1 to 8 Bar
Low pressure (0.5-2 Bar) & High pressure (5-15 Bar) versions available on request.

Temperature

-10°C to +95°C

Description

Stainless Steel Safety Valve. PTFE Seal. PED 2014/68/EU.

Stock Availability

Subject to factory lead time.

Connection

BSP Parallel Female (ISO 228/1)

Pressure

Up to 70 Bar Rated.

Temperature

-60°C to +225°C

Description

Brass Atmospheric Discharge Safety Valve. PTFE Seal.

Stock Availability

Subject to factory lead time.

Connection

Male BSP Parallel (ISO 228)

Approvals/ other

Complies to PED 2014/68/EU

Pressure

Set pressure: 0.2 to 50 bar

Temperature

-60°C to +225°C
